    PCB Labeling Machine with Intelligent / Handy Functions & 0.05mm Automatic Vision

    Ask Lasest Price
    Brand Name : Chuangwei
    Model Number : CWPP-T2
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 100 sets
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    PCB Labeling Machine with Intelligent / Handy Functions & 0.05mm Automatic Vision

    PCB Labeling Machine with Intelligent / Handy Functions & 0.05mm Automatic Vision Specifications:


    Mount accuracy±0.05mm
    Positioning accuracy±0.025mm
    Repeat positioning accuracy±0.05mm
    Mounting Speed1.5-2.5sec/pcs
    Component RangeMin:L5*W5mm,Max:L80*W40mm
    PCB sizeMax:L340*W280mm
    PCB Thickness0.5-6.5mm
    Feeder capacityStandard: 2 feeders(80mm)
    Positioning methodMARK point & screen frame for visual positioning+parts visual compensation
    Mount head number2PCS
    Entry wayL-R R-L L-L R-R
    Machine DimensionL1130*W1096*H1426mm
    Power Supply200-240V 50/60Hz single phase AC 200-240V 50/60Hz
    Power1.0KW
    Pressure0.4-0.6Mpa Dry air 0.4-0.6 bar
    Machine WeightAbout 800KG

    Machine Features:

    1. Mounting speed:1.3-2.5 sec/pcs
    2. High Precision:The mounting element adopt the camera to identify the positioning,PCB positioning using Mark camera ,precise positioning (two positioning ).
    3. Economic and convienent Nozzle: The Z axis buffer mechanism is designed on the mounting head to avoid the complexity of the nozzle design to ensure the safety of the product and to reduce the cost of the nozzle ,Easy to Changeover and increase throughout greatly.
    4. When installing the components, the torque mode is adopted to protect the product and prevent the damage.
    5. The vision system supports read date for one dimensional code, two-dimensional code.
    6. Stable and perfect control system, support various materials,production methods and other application etc.
    7. With the EMS system to achieve online production.

    Standard platform,Smart Accommodation


    Accommodates for electronic products like mobile,various PCB,SMT produce line and FPC,camera ,LED chip etc,which will replace labour for place pressure sensitive adhesive,conductive adhesive,double-face sticker , Thermal conductive silicone foam ,shield laminating ,label,protecting film and bar code ,QR code etc.


    Configuration:

    1. 0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area
      High precision and stable structure integrated frame to ensure stability for high speed mounting work.
    2. 0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area
      High optimized electric control box structure, compact and safe electric arrangement, which can effectively save and ensure the convenience of miantenance.
      3.0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area
      Adopt high precision servo motor and high precision screw guide rail are used to form a complete closed loop control system to ensure repeatability positioning accuracy.
      4.0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area

      High precision vision system hardware is composed of two high resolution cameras, according to a specific stable and efficient positioning algorithm,with multi axis mount head to improve efficiency greatly.

      5.0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area

      Two simple operation electronic smart feeder which Accurate feeding and easy to changeover and could be customized according to customer requirements of specifications of automatic feeding device.
      6.0.05mm Mount Accuracy Automatic Sticker Machine with 320*280mm Working Area
      Double mounting nozzles is controled independently which improve high mounting precision greatly and can mounting two different materials at the same time.
