Living Show Pro Audio Sound System 4 input / 8 ouput with Free
Routing
Quick Detail:
4 inputs and 8outputs with free routing
Intuitive handling at the front-panel and via PC software
4 equalizers p. input ch. (low-/high-shelf/parametric)
8equalizers p. output ch. (low-/high-shelf/parametric)
Symmetric inputs and outputs via XLR connectors
Analog and digital (AES/EBU©) inputs
High performance 32-bit DSP (digtial sound processor)
Security functions (lock front panel, etc.)
Description:
The SP4800 is a digital 4-in / 8-out speaker management matrix system with an
internal resolution of 32 bit and 96 kHz sampling rate. The SP2600 is equipped with 2 analog inputs, 6 analog outputs and one
remote-connector(USB). The use of modern and fast DSPs enables a
latency (analog to analog) of 0,625 ms only. Each input channel
includes 6 equalizers (with low-shelf, high-shelf and parametric
function), and a delay function. The polarity of each input channel
can be switched from + to -. Each output channel includes 6
equalizers (with low-shelf, high-shelf and parametric function) and
a delay function. The HPF (high-pass filter) and the LPF (low-pass
filter) is part of each output channel. Both offer three different
operation modes: Linkwitz-Riley, Butterworth and Bessel (up to 48
dB/Oct). Each output channel includes a high performance limiter.
The integrated flash memory chip offers space for 30 presets which
can be loaded via the preset-menu, three default-buttons or the PC
remote software.
The DSP can be adjusted and controlled with the free PC software.
This software is a professional tool and enables a quick and
effective programming of presets in real-time (online or offline).
The program shows adjustments of any filter in a graphic
simulation. All DSP-functions and adjustments can be loaded, edited
and saved with this tool. The software is compatible with WINDOWS
98©, WINDOWS 2000©, WINDOWS XP©, WINDOWS VISTA© and WINDOWS 7© (all
32-bit and 64-bit versions).
Applications:
Concert, living event. night club, disco and other applications
Specifications:
SP2600
Input Channel & Jacks : 4 Channel Female XLR
Output Channel & Jacks : 8 Channel male XLR
nput Impedancebalanced:20KΩ
Output impedance balanced:100Ω
PC PORT: 1 USB port on front panel, 2 RS485(RJ45) ports on rear
panel
CMRR >70dB(1KHz)
NPUT RANGE ≤+25dBu
FREQUENCY RESPONSE: 20Hz-20KHz
SNR>110Db
THD<0.01% OUTPUT=0dBu/1KHz
Channel Isolation>80dB(1KHz)
ABOUT HLA:
Languan Audio is one of professional audio speaker manufacturer in
China, which specialized in designing and manufacturing
professional audio systems,including PA speaker,indoor and outdoor
line array speaker,subwoofer,floor monitor, power amplifier and
speaker management system. We provide these products for indoor and
outdoor events, stadiums, churches, performing arts venues,
theatres,conference rooms, meeting halls, and any space where audio
system are needed.
Competitive Advantage:
Easy operation, good sound quality, high stability, fixed with good
electronic components,
