China PE PP ABS PVC Sheet Production Lines Automatic for sale

Video

PE PP ABS PVC Sheet Production Lines Automatic

Name: PE PP ABS PVC Sheet Production Lines Automatic
Brand: Qingdao Huashida Machinery Co., Ltd.

PE PP ABS PVC Sheet Production Lines Product Description The PE (Polyethylene) and PP (Polypropylene) Sheet Board Extrusion Line is a highly efficient production system designed to manufacture high-quality plastic sheet boards. This advanced extrusion line is capable of processing both PE and PP materials, offering versatility in producing various types of sheet boards with different thicknesses and sizes. Equipped with precision extrusion equipment and advanced cooling

Screw No. Single-screw

Automation Automatic

Place of Origin Qingdao , China

Size According to Customer′s Requirements

HS Code 8477209000

Packaging Details Standard Export Packing

pp diaphragm valve pvc slotted pipe interlocking pvc floor tile

Product Description

PE PP ABS PVC Sheet Production Lines

The PE (Polyethylene) and PP (Polypropylene) Sheet Board Extrusion Line is a highly efficient production system designed to manufacture high-quality plastic sheet boards. This advanced extrusion line is capable of processing both PE and PP materials, offering versatility in producing various types of sheet boards with different thicknesses and sizes. Equipped with precision extrusion equipment and advanced cooling systems, it ensures consistent product quality and high production efficiency. The line is also designed with user-friendly interfaces and automated control systems, making it easy to operate and maintain. Whether for packaging, construction, or other industrial applications, this extrusion line can meet diverse production needs and contribute to the efficient manufacturing of plastic sheet boards.

Model: 1200 width

Sheet Product Specification
Product	HDPE/PP sheets
Material	PE/PP granular
Max.width	1200mm
Thickness	2-14mm
Output capability	5-6T/day

More Production line models

(Modle)	(width)	Thickness(MM)	Speed(m/min)	Outputr(kg/h)
SBJZ-800	650	0.18-1.5	1-25	80-320
SBJZ -1000	800	0.2-2.0	1-20	150-430
SBJZ -1500	1350	1-10	0.5-10	150-450
SBJZ -2000	1850	2-15	0.5-8	300-550
SBJZ -2200	2000	1-10	0.4-3	420-820
SBJZ -3000	2850	2-8	0.2-3	500-1200
SBJZ -7000	6800	2-6	0.2-2	600-1560

Technical introduction:

PP/PE Sheet Extrusion line

The seller will support the buyer with complete technology of the lines and product.

Circumstance condition
Working place	Indoor
Power source	No dangerous area
Humidity	85% no condensation
Use Condition
Voltage and frequency	380V (-10%,+5%)380V 50HZ
Consumption of cooling water	~0.5m3/min(≤20ºC,0.3Mpa)
Requirement of compressed air	~0.4m3/min , >0.5Mpa
Installation capacity	Approx.150Kw
Dimension	14m3m3m
Output Capacity
Extruder Model	SJ90×30
Capacity	250Kg/h

Equipment List 1200 PE :

PE/pp-1200 PE sheet extrusion line
1.	Automatic vacuum feeder	1Set
2	Hopper Dryer	1Set
3	SJ-90×30 single screw Extruder	1 Set
4	T-Die mold	1 Set
5	Two Replacement Hydraulic screen changer	1Set
6	3-Calender Roller	1 Set
7	Roll temperature control system	1 Set
8	Cooling Bracket	1 Set
9	Haul-Off Unit	1 Set
10	Cutter	1set
11	Stacker	1set
12.	PLC	1set

1. Package : 1x40FCL
Packaged by wrapping film, the charge should be beard if used wooden pallet or wooden case demanded by buyer.

Quality guarantee
The guarantee period is 12 months for machinable parts, 6monthes for electrical parts. The period is from the day of loading the equipment from Seller's factory. But not more than 14 months from the date of delivery. After the end of the Guarantee period the Supplier is obliged to provide with lifelong service at the expense of Buyer.
During a warranty period of exploitation the Seller undertakes to execute warranty service of the equipment, troubleshooting and replacement of out of service spares, except for breakings, bound with incorrect exploitation of the equipment by the Buyer.

Seller provide the technical service with free, and training the workers of buyers.

Installation and testing
The seller can send engineers to the buyer's company for installation and testing the lines. The round trip ticket, accommodation, transportation, medicine treatment and insurance caused by the buyer's expert in buyer local and 150 US dollars per person per day will be paid by the buyer.
